Diesel Hydraulic Crawler Excavator CEG480-8 3.6 km/h 48 ton

Name: Diesel Hydraulic Crawler Excavator CEG4808 36 kmh 48 ton
Brand: BONNY
Price: 1 USD

Brand Name : BONNY

Model Number : CEG480-8

Certification : CE and ISO9001

Place of Origin : Jiangsu, China (Mainland)

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10 Set/Sets per Month

Delivery Time : 25-45 workdays after receive the advance payment

Packaging Details : One is nude packing and overall transport by sea with roll-on-roll-off ship.(L*W*H=13860*2900*3500 mm); The other is host in the flat rack,(L*W*H=9782*2800*3070 mm); kelly bar and bucket is also nude, meanwhile four wooden case which is put with mast, powe

color : red or printed

Name : large& super large hydraulic excavator

Condition : New

Operating Weight : 48t

Max.torque : 1674 Nm

Rated Speed : 3.2/5.2 km/h

Diesel engine power : 298kw

Contact Now

New BONNY 48ton CEG480-8 Diesel Hydraulic Crawler

Place of Origin:Wuxi, China (Mainland)
Brand Name:BONNY
Model Number:CED480-8
Condition:New
Moving Type:Crawler Excavator
Operating Weight:48t
Bucket capacity:1.6~2.5m³
Maximum Digging Height:10965mm/9920mm
Maximum Digging Depth:7760mm/2770mm
Machine Weight:48t
Max Digging Radius:12018mm/8550mm
Rated Speed:3.6 km/h
Certification:ISO9001
After-sales Service Provided:Engineers available to service machinery overseas
Electromotor:YJK3554-4
Rated Power:250kw
Voltage:6000V
Max.torque:1219 Nm
Max. pulling force:360kN
Type of undercarriage:H structure

No.	Item		Unit	Data
				Backhoe	Face shovel
1	Machine weight		t	48	50
2	Electromotor	Rated power	kW	250
		Rated voltage	V	6000
		Rated speed	r/min	1480
3	Hydraulic system	System pressure	MPa	32
		Max. flow	L/min	2×401
4	Swing device	Swing speed	r/min	8.3
		Tail swing radius	mm	3874
5	Pilot system	System pressure	MPa	4
		System flow	L/min	21.5
6	Traveling device	Traveling speed	km/h	3.62
		Ground pressure	MPa	0.0987(560mm track pad)
		Pulling force of the	kN	2×353.32
7	Working parameters	Boom specification	mm	7060	4100
		Stick specification	mm	3380	2700
		Bucket capacity of backhoe	m³	2.1	2.5
		Max. digging reach	mm	12018	8550
		Max. digging depth	mm	7760	2270
		Max. digging height	mm	10965	9920
		Max. dumping height	mm	7655	7370
		Max. digging force of stick	kN	217	269
		Max. digging force of bucket	kN	236	271

Diesel Hydraulic Crawler Excavator CEG480-8 3.6 km/h 48 ton
Mining hydraulic excavator is featured with:

1.Face-shovel and backhoe are covered from 40-220t.
2.Diesel engine or power driven is available for the excavator with 46t and above.
3.Voltage grade for power driven excavator 380V low voltage or 6000V high voltage.

Technology
1)6000V high voltage power supply
2)Malfunction diagnose,monitoring
3)GPS real time remote monitoring system
4)Application in extreme cold region
5)Application at high altitude
6)Suitable to application on all kinds of mines
Diesel Hydraulic Crawler Excavator CEG480-8 3.6 km/h 48 ton

Advantages:

We are the professional & trustwothy manufacturer of piling machinery in China, best quality & best service
Supply professional customized service to meet all your requirements.
Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.
Competitive price.
